PRODUCTS ABI Electronics

Test and Measuring Equipment and PCB Faultfinding Systems

Low Cost IC Test and PCB Diagnostic Systems including the BoardMaster, Compact Range and SYSTEM 8 Series.

BoardMaster 8000 Plus

The ABI BoardMaster 8000 PLUS Universal Diagnostic System is a uniquely versatile, self-contained and Easy-to-use test system. It offers the most comprehensive Set of test instruments for fault-finding on almost any kind of PCB. With the full range of instruments and a variety of test methods guaranteeing the best possible fault coverage, the Boardmaster 8000 Plus provides the ultimate in diagnostic tools.

Find Faults & Repair PCB's with ABI's SYSTEM8 Click Here to Watch Video

Click here for more information on this product.


System 8 Diagnostic Solution

The SYSTEM 8 Diagnostic Solution is the solution to board fault-finding problems. Equally at home with analogue or digital PCBs, the system's 64 digital and 24 analogue test channels provide a variety of fault-finding techniques to track down the most elusive faults. The in-circuit IC test is the heart of the digital fault-finding system - look into an IC, and check that it functions correctly, look outside, and confirm that it is correctly wired. Use the analogue V-I tester, with selectable test frequencies and voltages, to check discrete analogue components. Compare the results with a known good board, automate fault-finding procedures with the test sequence generator, and fault diagnosis becomes truly effortless!

Click here for more information on this product.

CircuitMaster 4000M

The CircuitMaster 4000M Precision Active Oscilloscope is unlike any other oscilloscope as it provides some innovative test and measurement functions that enable engineers and technicians to perform several new types of circuit analysis.

The CircuitMaster 4000M is designed for safe probing of closely spaced components by adding precision DC measurement, signal storage and analysis functions to a traditional oscilloscope design. Indeed, a built in accurate voltmeter (24 bit) removes the need for multiple instruments, thus making the CircuitMaster a complete test and measurement station. In addition, the Active mode allows signals (AC and DC) to be injected into the board when required, allowing circuit conditions such as drive strength and source impedance to be checked – which is not possible with traditional oscilloscopes. In AC Active mode, the unit behaves much like a function generator. The CircuitMaster even has a built-in LogicView 4 channel analyser for logic signal display along with the 2 analogue inputs. FirmFlex and VI Curve functions provide impedance signature analysis on powered and un-powered boards.

Click here for more information on this product.








JTAGMaster Boundary Scan Tester and Programmer

The JTAGMaster Tester and Programmer is a fully integrated solution for the configuration and diagnosis of Programmable Logic Devices (PLDs). This unit includes :

  • A boundary-scan tester to arbitrarily observe individual pins and therefore determine their functionality. This information can be saved in customisable test procedures which can also include pictures and datasheets. EXTEST mode is also available to manually change the state of pins and trace the effect(s) on the other device(s) in the chain. Scan Check is a multi-license software to run boundary scan checks on multiple stations.
  • A programming interface designed to handle industry standard JAM STAPL files (Standard Test And Programming Language) and SVF files (Serial Vector Format) to send programming instructions as well as testing functions to the device. ABI uses the JTAG Standards (Joint Test Action Group, compatible with IEEE1149.1) which ensures compatibility between all compliant ICs.

The JTAGMaster is also capable of programming EEPROM devices using external adapters.

Click here for more information on this product.


System 8 Multiple Instrument Station (MIS)

The SYSTEM 8 Multiple Instrument Station provides no less than 8 high specification test and measurement instruments in one compact module. Ideal for design or education, or for general purpose work bench use, the MIS really is a complete laboratory on your PC.

The MIS Comprises:

  • Digital storage oscilloscope
  • Floating digital multimeter
  • Frequency counter
  • Auxiliary power supply
  • Function generator
  • Quad programmable analogue I/O
  • Quad digital I/O
  • TestFlow manager
  • Automated fault-finding sequences
  • Customisable instruments

Each instrument may be customised like a virtual instrument to suit special applications.

The Multiple Instrument Station can be fitted inside a standard PC case with PCI interface (one empty CD-ROM bay required) or inside an external case (MultiLink) with USB interface

Click here for more information on this product.

Sentry Counterfeit IC Detector

The ABI SENTRY is a unique solution for the quick and easy detection of Counterfeit ICs and components. ABI Electronics has over 27 years of experience in the field of Test & Measurement equipment as well as Contract Electronics Manufacturing. Knowledge of both industries has allowed ABI to design this product around two main concepts:

- To offer a simple and easy to use system that can be operated by any personel, and particularly non-technical staff.

- To provide a powerful solution that would lead to the detection of counterfeit devices, thus protecting a business from very high unexpected costs.

Click here for more information on this product.


Chipmaster Compact Professional

Low-cost hand-held battery operated out-of-circuit IC testers. Choose the ChipMaster Compact for testing digital ICs with up to 40 pins, or the LinearMaster Compact for analogue ICs up to 16 pins. Both include a search facility for unknown ICs and loop modes for intermittent failure detection. Battery eliminators available for extended use. Two year warranty, free software updates and ABI test technology built-in.

Click here for more information on this product.

LinearMaster Compact Professional
Low-cost hand-held battery operated out-of-circuit IC testers. Choose the ChipMaster Compact for testing digital ICs with up to 40 pins, or the LinearMaster Compact for analogue ICs up to 16 pins. Both include a search facility for unknown ICs and loop modes for intermittent failure detection. Battery eliminators available for extended use. Two year warranty, free software updates and ABI test technology built-in.

Click here for more information on this product.
